3057-BK005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

3057-BK005

Hook-up Wire 16AWG 2.41mm Tinned Copper Black 300VAC - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3057-BK005 is a single-conductor hookup wire featuring 16 AWG stranded copper (26/30) conductor with 0.016" nominal PVC insulation wall thickness. It is rated for 300V RMS and operates reliably across a temperature range of -40°C to 105°C, meeting UL AWM styles 1569 and 1007 standards with VW-1 flame rating. The wire exhibits a nominal inductance of 0.04 µH/ft and a conductor DC resistance of 4.4 O/1000ft at 20°C, with a maximum pull tension of 20.4 lbs and a minimum bend radius of 10 times the cable diameter. This hookup wire is ideal for general-purpose electrical interconnections, control circuits, and internal wiring applications in consumer and industrial equipment where compact routing and reliable performance are required.

Search Keywords: 3057BK005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
3057-BK005
Alias/AKA:
3057-BLACK-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
16 AWG
Bunch Stranding:
26x30
Conductor Material:
Tinned Copper
Cable Diameter:
2.38 mm
Maximum Voltage Rating:
300 V
Operating Temperature:
-40 to 105 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 18

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$103.98
5
$96.22
10
$93.43
20
$88.31
50
$85.96
100 +
$84.83
