3057-YL005

Name: 3057-YL005
Brand: Alpha Wire
SKU: 10122390
Price: 153.21 USD
Availability: InStock

Alpha Wire

Hook-up Wire 16AWG 2.41mm Tinned Copper - Yellow - 300VAC - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 3057-YL005 is a single-conductor hookup wire designed for general-purpose electrical interconnections and wiring applications. It features a 16 AWG tinned copper conductor (26/30 stranding) with a nominal 0.016" wall PVC insulation, providing a total diameter of 0.092" ± 0.002". The wire is rated for 300 V RMS and operates across a temperature range of -40°C to 105°C, with a maximum pull tension of 20.4 lbs and a minimum bend radius of 10 times the cable diameter. Electrical characteristics include a nominal inductance of 0.04 µH/ft and a conductor DC resistance of 4.4 O/1000 ft at 20°C. This wire is commonly used in control circuits, instrumentation, and low-voltage power distribution where reliable insulation and temperature stability are required, and it is available in multiple colors including yellow (YL005 designation) and complies with RoHS and REACH regulations.

Product Highlights:

Potential Applications:

Search Keywords: 3057YL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3057-YL005

Alias/AKA:

3057-YELLOW-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99
