3071-WH005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

3071-WH005

Hook-up Wire 22AWG 2.38mm Tinned Copper - White - 600V - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3071-WH005 is a single-conductor hookup wire designed for general-purpose electrical applications requiring 600V rated insulation. It features a 22 AWG (7/30) tinned copper conductor with a nominal 0.032" wall PVC insulation, meeting UL AWM Style 1015/1230 and CSA standards for 105°C operation. The wire operates reliably across a temperature range of -40°C to 105°C with a maximum pull tension of 5.5 lbs and a bend radius of 5 times the cable diameter. This hookup wire is commonly used in control circuits, instrumentation, and general wiring applications where compact gauge and flexible routing are required.

Search Keywords: 3071WH005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
3071-WH005
Alias/AKA:
3071-WHITE-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
22 AWG
Bunch Stranding:
7x30
Conductor Material:
Tinned Copper
Cable Diameter:
2.38 mm
Maximum Voltage Rating:
600 V
Operating Temperature:
-20 to 105 °C
Color:
White
  Different packaging options available.  See Alternatives

IN STOCK: 8

Can Ship immediately

Manufacturer Stock: 3   can ship 11/16/26

Factory Lead-Time 9 Weeks can ship 1/4/27

Price (USD)

Qty
Unit Price
1
$56.19
5
$50.13
10
$48.64
25
$46.56
50
$44.64
100
$43.45
250 +
$42.88
