3469C-SL005

Name: 3469C-SL005
Brand: Alpha Wire
SKU: 10123236
Price: 589.48 USD
Availability: InStock

Multi-Conductor Cable Tape Semi Rigid Polyvinyl Chloride 9 Conductors 28AWG 6.01mm 300VAC - Slate - 30.48m (100ft)/Spool ...

View Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3469C-SL005 is a 9-conductor shielded cable assembly designed for reliable signal transmission in industrial and electronic applications. It features 9 conductors of 28 AWG tinned copper (7/36 stranding) with 0.010" nominal PVC insulation, twisted at 6.9 twists per foot minimum, and protected by an aluminum/mylar tape shield with 25% overlap and 65% minimum tinned copper braid coverage. The cable is rated for 300 V RMS with a temperature range of -20°C to +80°C, a bend radius of 10 times the cable diameter, and a maximum pull tension of 16.4 lbs. Electrical characteristics include a conductor DC resistance of 66 O/1000 ft at 20°C, capacitance of 25 pF/ft at 1 kHz, and inductance of 0.22 µH/ft. This cable is ideal for control systems, instrumentation, and data acquisition where multi-conductor shielding and signal integrity are essential.

Product Highlights:

Potential Applications:

Search Keywords: 3469CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3469C-SL005

Alias/AKA:

3469C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
