5192C-SL005

Name: 5192C-SL005
Brand: Alpha Wire
SKU: 10125485
Price: 409.23 USD
Availability: InStock

Multi-Conductor Cable 2 Conductors 22AWG 4.6mm 300V - Gray -30.48m/152.4m/304.8m - 30.48m (100ft)/Spool ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 5192C-SL005 is a two-conductor shielded cable assembly designed for general-purpose signal transmission and control applications. It features 22 AWG tinned copper conductors with 0.010" PVC insulation, twisted at 12.0 twists per foot minimum, and protected by an aluminum/mylar tape shield with a 22 AWG tinned copper drain wire. The cable is rated for 300V RMS at temperatures ranging from -35°C to 105°C, with a characteristic impedance of 48O and low capacitance of 39 pF/ft conductor-to-conductor. The outer PVC jacket is 0.032" wall thickness with a nominal diameter of 0.172 inches, available in multiple colors with a ripcord for easy stripping. This cable is ideal for instrumentation, audio/video signal routing, and industrial control systems where shielding and reliable signal integrity are required.

Product Highlights:

Potential Applications:

Search Keywords: 5192CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

5192C-SL005

Alias/AKA:

5192C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
