5853-GR001 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5853-GR001

The 5853-GR001 is a 26 AWG hook-up wire featuring a silver-plated copper conductor and PTFE insulation for high-temperature applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5853-GR001 is a high-performance hook-up wire designed for the internal wiring of electronic equipment. It is constructed with a 26 AWG (7/34) stranded, silver-plated copper conductor and is insulated with a nominal 0.010" wall of PTFE. This wire is rated for 600 VRMS and has a wide operating temperature range of -60°C to 200°C. Compliant with MIL-W-16878/4 (Type E) and UL AWM Style 1213 specifications, it is ideal for use in demanding military, aerospace, and industrial applications where high temperatures and reliability are critical.

Search Keywords: 5853GR001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5853-GR001
Alias/AKA:
5853-GREEN-1000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
26 AWG
Bunch Stranding:
7x34
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.09 mm
Maximum Voltage Rating:
600 VAC
Operating Temperature:
-60 to 200 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 21

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$999.12
3
$940.25
5 +
$882.18
Log in for special pricing

Tools/3D Models

Product Guides
