5853-VI005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5853-VI005

Hook-up Wire 26AWG 1.09mm Silver Plated Copper 600VAC - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5853-VI005 is a single-conductor hookup wire designed for high-temperature and high-voltage applications. It features a 26 AWG (7/34) stranded silver-plated copper conductor with a 0.010" nominal PTFE insulation wall, providing an overall diameter of 0.039" ± 0.004". The wire is rated for 600V RMS and operates reliably across a temperature range of -60°C to 200°C, meeting UL AWM/STYLE 1213 VW-1 and MIL-W-16878/4 (Type E) specifications. Key electrical properties include a nominal inductance of 0.06 µH/ft and a conductor DC resistance of 38 O/1000ft at 20°C. This wire is ideal for aerospace, military, and industrial applications requiring robust insulation and thermal stability, with a maximum pull tension of 2.18 lbs and a minimum bend radius of 10 times the cable diameter.

Search Keywords: 5853VI005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5853-VI005
Alias/AKA:
5853-VIOLET-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
26 AWG
Bunch Stranding:
7x34
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.09 mm
Maximum Voltage Rating:
600 VAC
Operating Temperature:
-60 to 200 °C
Color:
N/R

IN STOCK: 4

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$133.77
5
$123.79
10
$118.48
20
$113.61
50
$110.58
100 +
$109.13
