5854/7-OR005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5854/7-OR005

Hook-up Wire 24AWG 1.12mm Silver Plated Copper - Orange - 600V Spool - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

5854/7-OR005 is a single-conductor hookup wire designed for high-temperature and high-voltage applications. It features a 24 AWG (7/32) stranded copper conductor with a 0.010" nominal PTFE insulation wall, providing an outer diameter of 0.044" ± 0.004". The wire is rated for 600V RMS and operates across a temperature range of -60°C to 200°C, meeting UL AWM/STYLE 1213 VW-1 and MIL-W-16878/4 (Type E) specifications. With a maximum pull tension of 3.5 lbs and a minimum bend radius of 10 times the cable diameter, this wire is suitable for aerospace, military, and industrial applications requiring reliable performance in extreme thermal and electrical environments.

Search Keywords: 58547OR005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5854/7-OR005
Alias/AKA:
5854/7-ORANGE-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
24 AWG
Bunch Stranding:
7x32
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.12 mm
Maximum Voltage Rating:
600 V
Operating Temperature:
-60 to 200 °C
Color:
N/R

IN STOCK: 4

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$143.89
5
$133.15
10
$127.44
20
$122.21
50
$118.95
100 +
$117.39
