5855/7-SL005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5855/7-SL005

Hook-up Wire 22AWG 1.27mm Silver Plated Copper - Slate - 600V Spool - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5855/7-SL005 is a high-temperature hookup wire designed for demanding electrical applications requiring reliable insulation and conductor performance. It features a 22 AWG (7/30) stranded copper conductor with a nominal 0.010" wall PTFE insulation, providing excellent chemical resistance and thermal stability. The wire is rated for 600V RMS and operates across a temperature range of -60°C to 200°C, meeting both UL AWM/STYLE 1213 and MIL-W-16878/4 (Type E) specifications. With a bend radius of 10 times the cable diameter and a maximum pull tension of 5.5 lbs, this wire is suitable for aerospace, military, industrial control, and high-temperature instrumentation applications where durability and compliance with stringent standards are essential.

Search Keywords: 58557SL005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5855/7-SL005
Alias/AKA:
5855/7-SLATE-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
22 AWG
Bunch Stranding:
7x30
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.37 mm
Maximum Voltage Rating:
600 VAC
Operating Temperature:
-60 to 200 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 2

Ships today, if you order in

Manufacturer Stock: 4   can ship 11/16/26

Factory Lead-Time 16 Weeks can ship 2/22/27

Price (USD)

Qty
Unit Price
1
$152.77
5
$150.70
10
$149.70
20
$147.79
50
$146.88
100 +
$145.13
