5856-WH005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5856-WH005

The 5856-WH005 is a 20 AWG hook-up wire featuring a silver-plated copper conductor and PTFE insulation for high-temperature applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5856-WH005 is a single-conductor hook-up wire designed for the internal wiring of electronic equipment. It is constructed with a 20 AWG (19/32 stranding) silver-plated copper conductor and a nominal 0.010" wall of PTFE insulation, resulting in an overall diameter of 0.058 inches. This wire meets MIL-W-16878/4 (Type E) specifications, supporting a voltage rating of 600 VRMS and a wide operating temperature range from -60°C to 200°C. Its robust thermal and electrical characteristics make it ideal for demanding military, aerospace, and industrial applications where high performance and reliability are essential.

Search Keywords: 5856WH005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5856-WH005
Alias/AKA:
5856-WHITE-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Size:
20 AWG
Bunch Stranding:
19x32
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.5 mm
Maximum Voltage Rating:
600 V
Operating Temperature:
-60 to 200 °C
Color:
White
  Different packaging options available.  See Alternatives

IN STOCK: 8

Ships today, if you order in

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$286.53
5
$259.52
10
$249.61
20
$241.33
50
$222.77
100 +
$222.21
Log in for special pricing Click for Quote Price Match Request
