6307-SL005

Name: 6307-SL005
Brand: Alpha Wire
SKU: 10129747
Price: 365.65 USD
Availability: InStock

Multi-Conductor Cable - 15 Conductors - 24 AWG - 7/32 Conductor Strand - 300V - Slate Jacket - 30.48m (100ft)/Spool. ...

View Datasheet Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 6307-SL005 from Alpha Wire is multi-conductor cable with 15 conductors, 24 AWG wire gauge, 7/32 conductor strand and 300V voltage rating. This cable has tinned copper conductor, poly-vinyl chloride (PVC) conductor insulation, aluminum foil shield (100% coverage) and slate color poly-vinyl chloride (PVC) jacket with 0.270" (6.86mm) diameter. Operating temperature range is from -20°C to 80°C.

Product Highlights:

Potential Applications:

Search Keywords: 6307SL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

6307-SL005

Alias/AKA:

6307-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
