6713-BL005

Name: 6713-BL005
Brand: Alpha Wire
SKU: 39133302
Price: 79.58 USD
Availability: InStock

Hook Up Wire - Stranded - 22 (7/30) AWG - 600V - mPPE - Blue - 100 ft - Tinned Copper ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 6713-BL005 is a single-conductor 22 AWG hookup wire manufactured by Alpha Wire with a tinned copper conductor and modified polyphenylene ether insulation. It is rated for 600 V RMS at 105°C continuous operation and complies with UL AWM/STYLE 11028 and CSA C(RU) AWM I A/B FT1 standards. The wire features a nominal insulation wall thickness of 0.0095 inches with an overall diameter of 0.049 ± 0.002 inches, a conductor DC resistance of 16.2 O/1000 ft at 20°C, and an inductance of 0.04 µH/ft. It operates reliably across a temperature range of -40°C to +105°C with a maximum bend radius of 10 times the cable diameter and a maximum pull tension of 5.5 lbs. This wire is ideal for general-purpose internal wiring, control circuits, and interconnections in industrial equipment, consumer electronics, and appliances where compact gauge and high-temperature performance are required.

Product Highlights:

Potential Applications:

Search Keywords: 6713BL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

6713-BL005

Alias/AKA:

6713-BLUE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
