Image is representational - see mfr. specs

7046-BK005

Alpha Wire

Hook-up Wire - Stranded - 14 (41/30) AWG - PVC Black - 100 ft - Tinned Copper ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

7046-BK005 is a 14 AWG single conductor hookup wire designed for general-purpose electrical connections. It features a tinned copper conductor with 41/30 stranding and cross-linked polyethylene (XLPE) insulation with a 0.032" wall thickness, providing an overall diameter of 0.138 inches. The wire is rated for a temperature range of -55°C to 125°C and a voltage rating of 600 VRMS, with UL AWM Style 3271 and CSA CL1251 certifications. It offers a conductor DC resistance of 2.8 O/1000ft and a maximum pull tension of 32 lbs. This RoHS-compliant wire is suitable for applications requiring reliable performance in demanding environments, including industrial equipment and control systems.

Product Highlights:

Potential Applications:

Search Keywords: 7046BK005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

7046-BK005

Alias/AKA:

7046-BLACK-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
