86602CY-SL005

Name: 86602CY-SL005
Brand: Alpha Wire
SKU: 10132893
Price: 403.7 USD
Availability: InStock

Multi-Pair Cable - 4 (2 Pair Twisted) Conductors - 24 AWG - 10/34 Conductor Strand - 300V - Slate Jacket - 30.48m (100ft)/Spool. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 86602CY-SL005 from Alpha Wire is multi-pair cable with 4 (2 pair twisted) conductors, 24 AWG wire gauge, 10/34 conductor strand and 300V voltage rating. This cable has tinned copper conductor, poly-vinyl chloride (PVC) conductor insulation, aluminum/tinned copper foil/braid shield (100%/85% coverage) and slate color poly-vinyl chloride (PVC) jacket with 0.260" (6.60mm) diameter. Operating temperature range is from +5°C to 105°C.

Product Highlights:

Potential Applications:

Search Keywords: 86602CYSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

86602CY-SL005

Alias/AKA:

86602CY-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
