86605CY-SL005

Name: 86605CY-SL005
Brand: Alpha Wire
SKU: 10132914
Price: 620.65 USD
Availability: InStock

Alpha Wire

Data Cable 10 Conductors 24AWG 7.82mm 300V - Gray -30.48m/152.4m/304.8m Bulk - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 86605CY-SL005 is a 5-pair shielded twisted-pair data cable designed for continuous flex applications and high-reliability signal transmission. It features 24 AWG tinned copper conductors with 0.010" PVC insulation, organized into 5 twisted pairs with a minimum of 9.6 twists per foot, and wrapped with nonwoven polyester tape. The cable incorporates a flexible aluminum/mylar shield with 25% overlap and tinned copper braid at 85% coverage minimum, along with a 26 AWG tinned copper drain wire for grounding. The outer jacket is 0.040" nominal PVC in slate color with a 0.314" ±0.016" overall diameter, providing robust environmental protection. This cable is rated for 300V RMS at 105°C, complies with UL AWM styles 2661 and 21894, CSA FT4, and is RoHS-compliant, making it suitable for industrial control systems, data acquisition, and continuous-flex applications requiring reliable signal integrity and durability.

Product Highlights:

Potential Applications:

Search Keywords: 86605CYSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

86605CY-SL005

Alias/AKA:

86605CY-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
