881802-SL005

Name: 881802-SL005
Brand: Alpha Wire
SKU: 39135346
Price: 116.04 USD
Availability: InStock

Slate - 30.48m (100ft)/Spool ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 881802-SL005 is a two-conductor control cable featuring 18 AWG stranded tinned copper conductors (16/30 stranding) with individual PVC insulation and an overall PVC jacket. The cable is constructed with two components cabled together at 5.3 twists per foot minimum, with a slate-colored outer jacket printed with UL TYPE CL2 90°C and AWM 2464 80°C 300V ratings. It is rated for 300 VRMS with a characteristic impedance of 65 O, capacitance of 33 pF/ft at 1 kHz, and a conductor DC resistance of 7.1 O/1000 ft at 20°C. The cable operates over a temperature range of -20°C to +90°C, supports a maximum pull tension of 25 lbs, and has a minimum bend radius of 10 times the cable diameter. This cable is commonly used in low-voltage control, instrumentation, and signal transmission applications where reliable, compact two-conductor connectivity is required.

Product Highlights:

Potential Applications:

Search Keywords: 881802SL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

881802-SL005

Alias/AKA:

881802-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
