9188A-WH005

Name: 9188A-WH005
Brand: Alpha Wire
SKU: 10133281
Price: 371.57 USD
Availability: InStock

The 9188A-WH005 is a 25 AWG, 50 Ohm coaxial cable compliant with MIL-C-17D/69B RG 188A/U standards, featuring PTFE insulation and jacket for high-temperature applications. ...

View Datasheet Ask the Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance

DESCRIPTION

The 9188A-WH005 is a high-temperature, military-grade coaxial cable designed for reliable signal transmission. It is constructed with a 25 AWG silver-coated copper weld conductor, PTFE insulation, and a silver-plated copper braid shield that provides a minimum of 94% coverage. The cable, which has a white PTFE tape jacket and a nominal outer diameter of 0.105 inches, features a characteristic impedance of 50 Ohms. It is rated for an operating temperature range of -55Â°C to 200Â°C and a voltage of 900 VRMS. As a MIL-C-17D/69B RG 188A/U type cable, it is ideal for demanding military, aerospace, and high-performance electronic applications.

Product Highlights:

Potential Applications:

Search Keywords: 9188AWH005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

9188A-WH005

Alias/AKA:

9188A-WHITE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544200000

COO:

ECCN:

EAR99

Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
