EC09E1524418 by alps electric
Image is representational - see mfr. specs

EC09E1524418

Alps Electric

A 9mm incremental encoder with a 20mm metal shaft, 15 pulses, 30 detents, and an integrated push-on switch. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The EC09E1524418 is a vertical mount incremental encoder featuring an integrated push-on switch. It is designed with 30 detent positions and provides 15 pulses per revolution, with a detent torque of 8±5 mN·m. This model includes a 20mm flat metal shaft and a push-on switch with 1.5mm of travel. Rated for 10mA 5V DC, it operates across a temperature range of -40°C to +85°C and has an operating life of 15,000 cycles. Its compact design makes it ideal for user interface controls in various electronic devices requiring precise input and selection.

Search Keywords: EC09E1524418

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
EC09E1524418
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1400
Package Type:
TRAY
Built-in Switch:
Yes
Bearings:
N/A
Body Orientation:
Straight

IN STOCK: 1,400

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
10
$5.42
50
$4.52
250
$4.21
500
$3.87
1,400
$3.56
2,800
$3.54
5,600
$3.52
8,400 +
$3.50
Suppliers Standard Package
