DESCRIPTION

SRGAVC0301 is a hollow shaft rotary encoder from the SRGA series designed for absolute position detection with vertical operating direction. The encoder features 12 positions with a 30° changeover angle and outputs Gray code, making it suitable for applications requiring reliable position sensing. It operates with a torque rating of 20±10 mN·m and supports a maximum resistive load rating of 0.1A at 12V DC, with contact resistance maintained at 1O maximum both initially and after operating life. The device is rated for 10,000 cycles of operating life with or without load, and operates over a temperature range of 10°C to +70°C. This encoder is ideal for industrial control systems, user interface applications, and equipment requiring precise rotational position feedback with low maintenance requirements.
