SSSS916400 by alps electric
Image is representational - see mfr. specs

SSSS916400

Alps Electric

Switch Slide SPDT Side Slide 0.1A 12VDC 10000Cycles PC Pins Thru-Hole Bulk ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SSSS916400 is a compact slide switch from the SSSS9 series designed for general-purpose switching applications. This 1-pole, 2-position switch features a horizontal actuator direction with standard mounting method and non-shorting changeover timing. It offers a 2mm travel distance with a maximum rating of 0.1A at 12V DC and minimum rating of 1mA at 5V DC. The switch provides reliable performance with initial contact resistance of 30mO max and operating life of 10,000 cycles. Common applications include consumer electronics and portable devices where compact, user-friendly switching is required.

Search Keywords: SSSS916400

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
SSSS916400
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000
Package Type:
BULK
Mounting:
PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Side Slide
Pole Throw Configuration:
SPDT
Switch Configuration:
N/A
Contact Rating @ Voltage:
0.1@12VDC A
Contact Plating:
N/A
Operating Temperature:
-40 to 85 °C
Termination Style:
PC Pins
Dimension:
11.5 x 9.7 x 5 mm

IN STOCK: 26,522

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$1.149
250
$0.963
500
$0.895
1,000
$0.810
2,500
$0.782
5,000
$0.728
10,000
$0.727
15,000 +
$0.725
