AZ2800-2C-277A by american zettler
Image is representational - see mfr. specs

AZ2800-2C-277A

American Zettler

40AMP Power Relay 277VAC coil SPDT ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AZ2800-2C-277A is a 40 A miniature power relay designed for switching high-current AC loads in industrial and commercial applications. It features dual-pole contact arrangements (DPST with 2 Form A or DPDT with 2 Form C contacts) with a 277 VAC nominal AC coil rated at 14.4 mA nominal current and 4700 O coil resistance (60 Hz). The relay meets 8 mm creepage and 4 kV dielectric strength requirements, with contact ratings of 40 A at 277 VAC resistive (30k cycles), 30 A at 277 VAC general use (100k cycles), and operates with a 15 ms typical operate time and 10 ms typical release time. It is rated for -40°C to 65°C ambient operating temperature, withstands 0.062" displacement at 10–55 Hz vibration and 10 g operational shock, and is housed in a PBT polyester enclosure with quick-connect tab terminals. Common applications include HVAC systems, lighting control, motor starters, and power distribution in commercial buildings where 277 VAC switching is required.

Search Keywords: AZ28002C277A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ2800-2C-277A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Tray
Relay Construction:
Non-Latching10725
AC Coil Voltage:
277 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT10703
Mounting:
Flange Mount10716
Termination Style:
Quick Connect10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 65 °C

IN STOCK: 3

Can Ship immediately

Buy all 3 in-stock or the regular minimum order quantity of 5

On Order: 100   can ship 8/19/26

Stock lot only: 3

Minimum Order Quantity: 5

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$26.320
5
$23.927
10
$22.258
25
$20.034
50
$19.292
100
$18.169
300
$17.737
500 +
$17.119
Suppliers Standard Package
