AZ762-1A-24DE by american zettler
Image is representational - see mfr. specs

AZ762-1A-24DE

American Zettler

16A SPDT Mini Power Relay 24VDC coil SPST-NO ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AZ762-1A-24DE is a 16 amp miniature power relay designed for switching applications requiring compact size and reliable performance. It features 20 amp switching capability, 5 kV dielectric strength with isolation spacing of 10 mm or greater, and reinforced insulation according to IEC 60730-1 and IEC 60335-1 standards. The relay operates with a 24 VDC nominal coil voltage, 10.4 mA nominal current, and 2304 O coil resistance, with a maximum coil voltage of 62.6 VDC and must-operate voltage of 18.0 VDC. It provides maximum switched power of 480 W or 5540 VA at 20 A and 125 VDC or 440 VAC, with operate time of 7 ms typical and release time of 4 ms typical. The compact design features a low seated height of 15.7 mm, dimensions of 29.0 × 12.7 × 15.7 mm, and is suitable for industrial control, automation, and power switching applications where space constraints and high reliability are critical.

Search Keywords: AZ7621A24DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ762-1A-24DE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
TRAY
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 100 °C
Coil Resistance:
1.44 KOhm

IN STOCK: 583

Can Ship immediately

On Order: 2,000   can ship 12/16/26

Minimum Order Quantity: 25

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
25
$2.42
100
$1.97
250
$1.87
500
$1.82
1,000
$1.72
2,500
$1.52
5,000
$1.48
7,500 +
$1.40
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
