AZ8222-2C-12DSSE by american zettler
Image is representational - see mfr. specs

AZ8222-2C-12DSSE

American Zettler

Sub-Mini Ultra-Sensitive DIP Relay 12VDC coil DPDT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AZ8222-2C-12DSSE is a subminiature ultra-sensitive DPDT (2 Form C) DIP relay designed for low-power switching applications requiring compact board spacing and minimal coil power consumption. It features a 12 VDC nominal coil with 960 O coil resistance (±10%), 27.7 VDC maximum continuous voltage, and ultra-low 84 mW pickup power, enabling operation in power-constrained systems. The relay switches up to 2 A at 30 VDC or 1 A at 125 VAC with a maximum switching capacity of 60 W or 125 VA, utilizing silver nickel gold-plated bifurcated crossbar contacts with contact resistance below 100 mO. It operates across -40 °C to 85 °C ambient temperature, achieves 100 million mechanical operations and 100,000 electrical operations at 2 A/30 VDC, and meets FCC lightning surge (1500 V) and dielectric (1000 V) requirements. The relay fits standard 16-pin IC sockets, is epoxy sealed for automatic wave soldering, and is ideal for telecommunications, industrial control, and consumer electronics requiring reliable low-power switching in confined spaces.

Search Keywords: AZ82222C12DSSE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ8222-2C-12DSSE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
Tube
Relay Construction:
Non-Latching
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 80 °C
Dimension:
20.2 x 10 x 11.5 mm
Termination Style:
PC Pin
Coil Current:
13 mA
Contact Form:
2 Form C

IN STOCK: 175

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 1000

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
25
$2.03
250
$1.34
500
$1.30
1,000
$1.25
2,000
$1.24
3,000
$1.23
4,000 +
$1.22
