AZ850-5 by american zettler

AZ850-5

American Zettler

Electromechanical Relay DPDT 1A 5VDC 178Ohm Through Hole ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMERICAN ZETTLER part AZ850-5 is an electromechanical relay with DPDT (Double Pole Double Throw) configuration. It has a contact rating of 1A and operates at a voltage of 5VDC. The relay has a resistance of 178 Ohm and can be mounted through hole. This versatile and reliable relay is suitable for various applications where low voltage switching is required.

Search Keywords: AZ8505

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ850-5
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
14 x 9 x 5 mm
Termination Style:
PC Pin
Coil Current:
28 mA
Contact Form:
2 Form C

IN STOCK: 910

Ships today, if you order in

Minimum Order: 50

Multiple: 50

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
50
$2.618
250
$2.511
500
$2.496
1,000
$2.481
2,500
$2.465
5,000 +
$2.450
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
AZ850-4.5
AZ850-4.5
