AZ943-1CH-5DE by american zettler

AZ943-1CH-5DE

American Zettler

15AMP Mini PC Board Relay 5VDC coil SPDT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMERICAN ZETTLER part AZ943-1CH-5DE is a high-quality 15AMP Mini PC Board Relay designed to provide reliable switching performance. With a 5VDC coil, this SPDT (Single Pole Double Throw) relay is ideal for various industrial applications. It offers a compact design, making it suitable for space-constrained installations. With its high current-carrying capacity, this relay ensures efficient power transmission. Trust the AMERICAN ZETTLER AZ943-1CH-5DE for dependable and efficient switching solutions.

Search Keywords: AZ9431CH5DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ943-1CH-5DE
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 90 °C
Coil Resistance:
70 Ohm

IN STOCK: 5,415

Ships today, if you order in

On Order: 10,000   can ship 2/5/26

Minimum Order: 40

Multiple: 20

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
40
$2.389
260
$2.251
1,000 +
$2.098
Suppliers Standard Package
Log in for special pricing
Click for Quote
