AZ9871-1A-12DET by american zettler
Image is representational - see mfr. specs

AZ9871-1A-12DET

American Zettler

30AMP Micro Automotive Relay 12VDC coil SPST-NO ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMERICAN ZETTLER part AZ9871-1A-12DET is a high-quality micro automotive relay designed for efficient and reliable performance. With a 30AMP capacity and a 12VDC coil, this relay offers a powerful solution for various automotive applications. The single pole, single throw normally open (SPST-NO) configuration ensures seamless connectivity in your vehicle's electrical system. Whether you need to control lights, motors, or other devices, this relay is capable of handling the load. Count on the AZ9871-1A-12DET for exceptional durability and dependable functionality in automotive environments.

Search Keywords: AZ98711A12DET

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ9871-1A-12DET
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
30A
Coil Voltage:
12 VDC
Coil Current:
47.2 mA
Coil Resistance:
254 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
6.9 VDC
Must Release Voltage:
1.5 VDC
Operate Time:
3 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
13.2 x 12.3 x 10.2 mm
Operating Temperature:
-40 to 105 °C
Packaging:
N/A

IN STOCK: 3,900

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
100
$1.474
300
$1.427
500
$1.368
1,000
$1.314
2,500
$1.308
5,000
$1.212
7,500
$1.206
10,000 +
$1.200
