CS-DSDHD26MF0-015 by amphenol cables on demand
Image is representational - see manufacturer specifications
Amphenol Cables on Demand Authorized Distributor

CS-DSDHD26MF0-015

A 15-foot, male-to-female cable assembly featuring 26-pin high-density D-Sub connectors with a 1-to-1 pinout. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Bag Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The CS-DSDHD26MF0-015 is a 15-foot cable assembly designed for connecting devices with 26-pin high-density D-Sub interfaces. It features a male D-Sub connector on one end and a female D-Sub connector on the other, both with 26 pins in a high-density configuration. The cable is constructed with a grey jacket, 360° copper shielding, and a soldered drain wire for enhanced signal integrity and noise immunity. The connectors are secured with 4-40 UNC threaded thumbscrews on the male side and hex nuts on the female side, ensuring a stable connection with a direct 1-to-1 pinout for all 26 conductors.

Search Keywords: CSDSDHD26MF0015

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Cables on Demand
Part No:
CS-DSDHD26MF0-015
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544422000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Bag

IN STOCK: 56

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$73.47
5
$50.28
10
$42.28
25
$39.39
50
$36.78
100
$34.03
250 +
$33.95
Log in for special pricing

Tools/3D Models

Product Guides
