L77SDDH50SOL2RM8 by amphenol communications solutions (acs)
Image is representational - see manufacturer specifications
Amphenol Communications Solutions (ACS) Authorized Distributor

L77SDDH50SOL2RM8

Conn D-Subminiature SKT 50 POS 2.76mm Solder ST Thru-Hole 50 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The L77SDDH50SOL2RM8 is a 50-contact D-Sub connector featuring straight PCB termination in high-density configuration, designed for economical and reliable I/O connections. The connector utilizes precision formed contacts with closed-entry contact cavities and is constructed with steel shells with tin over nickel plating, glass-filled thermoplastic insulator (UL 94V-0), and brass pin contacts with selected gold in the mating area. Mechanical specifications include a maximum single contact insertion force of 0.54 kg (1.19 lb), mating force of 1.6 kg (3.56 lb) maximum, and unmating force of 2.02 kg (4.46 lb) minimum. The connector meets MIL C24308 and NFC 93425-HE5 standards and is RoHS compliant, making it suitable for industrial, telecom, and standard I/O connection applications requiring high reliability and quality.

Search Keywords: L77SDDH50SOL2RM8

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (ACS)
Part No:
L77SDDH50SOL2RM8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
TRAY
Type:
D-Subminiature3530
Body Orientation:
Straight3506
Mounting:
Through Hole3516
Gender:
F3507
Termination Method:
Solder3529
Shell Size:
53527
Number of Contacts:
50
Contact Plating:
Gold Over Nickel3509
Operating Temperature:
-55 to 125 °C

IN STOCK: 0

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$4.54
50
$4.05
120
$3.86
360
$3.63
600
$3.51
1,080
$3.39
2,520
$3.20
5,040 +
$3.11
Supplier's Standard Package
