48236-000LF by amphenol communications solutions (fci)
Image is representational - see mfr. specs

48236-000LF

Amphenol Communications Solutions (FCI)

The 48236-000LF is a Mini PVâ„¢ crimp-to-wire receptacle terminal designed for 22-26 AWG wire. ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 48236-000LF is a loose-piece Mini PV™ crimp-to-wire receptacle terminal. It is constructed with a 1/4 hard brass body and a Beryllium Copper (Be/Cu) spring, and is designed to accept 22-26 AWG wire. This lead-free terminal features Gold Flash plating in the contact box and wire barrel over a 50µ" Nickel underplate for a reliable connection. It is engineered to mate with 0.025" (0.64mm) square or round pins, making it suitable for various wire-to-board and wire-to-wire applications.

Search Keywords: 48236000LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
48236-000LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BULK
Contact Type:
Signal
Gender:
SKT
Contact Size:
N/A
Wire Size:
22-26 AWG
Contact Material:
Brass
Contact Plating:
Gold over Nickel
Maximum Current Rating:
3 A
Termination Method:
Crimp

IN STOCK: 10,528

Can Ship immediately

Minimum Order Quantity: 100

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
100
$0.3694
500
$0.2678
3,000
$0.2512
5,000
$0.2500
8,000
$0.2487
25,000
$0.2472
50,000 +
$0.2460
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
