69167-104HLF by amphenol communications solutions (fci)
Image is representational - see mfr. specs

69167-104HLF

Amphenol Communications Solutions (FCI)

Conn Shrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole MinitekA® Bulk ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 69167-104HLF is a single-row vertical friction latch header connector designed for reliable interconnection in electronic assemblies. This 4-position header features a glass-reinforced PCT body with black color, flame-retardant per UL 94 V-0, and is rated for a maximum operating temperature of 130°C. The connector incorporates 3/4 hard phosphor-bronze pins with lead-free plating (15 µm minimum over 50 µm minimum nickel), meeting European Union directives as described in GS-22-008. Key dimensional specifications include a mating length of 0.230 inches (5.84 mm), a tail length of 0.120 inches (3.05 mm), and a body width (DIM K) of 0.400 inches (10.16 mm). The friction latch design ensures secure mating and is commonly used in instrumentation, data acquisition, and consumer electronics applications where compact, reliable connections are required.

Search Keywords: 69167104HLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
69167-104HLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
BAG
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
4
Maximum Voltage Rating:
1000 VAC
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 95 °C

IN STOCK: 12,351

Ships today, if you order in

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 3000

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
50
$1.001
500
$0.785
1,000
$0.741
3,000
$0.649
6,000
$0.648
9,000
$0.641
12,000 +
$0.627
