8655MH3701BLF by amphenol communications solutions (fci)
Image is representational - see manufacturer specifications
Amphenol Communications Solutions (FCI) Authorized Distributor

8655MH3701BLF

D-Sub Accessories, Input Output Connectors, Straight Exit Metal Hood for 37 position connector - Economical series ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 8655MH3701BLF is a Size 37 D-Sub metal backshell assembly designed for high-frequency shielded connector applications. It features UNC 4.40 threading with a black plastic headscrew and is constructed from zinc die-cast material with nickel plating for corrosion resistance. The backshell incorporates a polycarbonate strain relief (UL94V-0) and supports cable diameters from 4.0 to 13.0 mm, with an attenuation factor exceeding 40 dB between 30 MHz and 1 GHz. Operating over a temperature range of -40°C to 120°C, it is rated for a maximum cover screwing force of 100 Ncm and jackscrew screwing force of 50 Ncm. This product is ideal for industrial, telecommunications, and high-reliability applications requiring robust EMI shielding and secure cable termination.

Search Keywords: 8655MH3701BLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
8655MH3701BLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DK
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
OTHER
Type:
Backshells
Shell Size:
C
Angular Function:
180 °
Operating Temperature:
-55 to 125 °C
Connector Type:
Connector D-Subminiature
Body Material:
Zinc Die Cast
Dimension:
70.9 x 15mm mm

IN STOCK: 100

Ships today, if you order in

On Order: 200   can ship 11/27/26

Minimum Order Quantity: 5

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
5
$10.29
25
$10.10
50
$8.74
100
$8.08
300
$7.73
500
$7.25
1,000
$6.67
2,500 +
$6.65
