DILB16P-223TLF by amphenol communications solutions (fci)
Image is representational - see mfr. specs

DILB16P-223TLF

Amphenol Communications Solutions (FCI)

Conn DIP Socket SKT 16 POS 2.54mm Solder ST Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

DILB16P-223TLF is a 16-position dual-in-line socket connector designed for reliable electrical interconnection in electronic assemblies. The connector features phosphor bronze pins with low tin/lead plating over 50 µm nickel, housed in a UL 94V-O polyester insulator body. It delivers a maximum contact resistance of 20 milliohms, a dielectric withstanding voltage of 1000 V, and a current rating of 1 ampere maximum per contact. With a minimum contact force of 1.2 lbs (5.0 grams) and insulation resistance of 500 megohms minimum, this connector is suitable for applications requiring robust signal and power distribution in industrial control systems, telecommunications equipment, and consumer electronics.

Search Keywords: DILB16P223TLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
DILB16P-223TLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
9000
Package Type:
TUBE
Type:
DIP Socket
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
200 VAC
Maximum Current Rating:
1/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 20,359

Ships today, if you order in

Minimum Order Quantity: 100

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
100
$0.2994
500
$0.2860
1,000
$0.2803
2,500
$0.2725
5,000
$0.2668
9,000
$0.2619
18,000
$0.2562
27,000 +
$0.2528
Suppliers Standard Package
