PT08SE-14-19S(SR) by amphenol industrial operations

Image is representational - see manufacturer specifications

Amphenol Industrial Operations Authorized Distributor

PT08SE-14-19S(SR)

Name: PT08SE-14-19S(SR)
Brand: Amphenol Industrial Operations
SKU: 45929558
Price: 168.64 USD
Availability: InStock

Conn Miniature Cylindrical SKT 19 POS Crimp RA Cable Mount 19 Terminal 1 Port ...

View Datasheet Ask the Datasheet

RoHS Non-Compliant

Certificate of Compliance

DESCRIPTION

PT08SE-14-19S(SR) is a 90-degree miniature cylindrical connector plug with crimp contacts and strain relief designed for cable support applications. This connector features a shell size 14 with an open wire seal configuration and strain relief clamp (SR) for moisture-proofing individual wires. The plug incorporates a bayonet coupling mechanism compliant with MIL-C-26482 Series 1 specifications and is manufactured by Amphenol Industrial Operations with standard olive drab, electrically conductive cadmium plating. Key dimensional specifications include a plug front view diameter (G) of 1.171 inches maximum, with side view dimensions of C ±0.010 to -0.025 inches, D ±0.062 inches, E ±0.047 to -0.025 inches, and a maximum length (L) of 2.406 inches. This connector is commonly used in aerospace, military, and industrial applications requiring reliable signal transmission and power distribution in compact, high-vibration environments.

Product Highlights:

Potential Applications:

Search Keywords: PT08SE1419SSR

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Industrial Operations

Part No:

PT08SE-14-19S(SR)

Alias/AKA:

71-332814-19S

Unit of Measure:

Per Each

RoHS:

HTS:

8536694020

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

IN STOCK: 39

Ships today, if you order in

BONDED Quantity: 0

Manufacturer Stock: 0

Stock lot only:

MOQ for out of Stock Qty:

Multiple: 1

Factory Lead-Time 16 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.

Price (USD)

Qty

Unit Price

$168.64

$162.93

$160.46

$158.00

$154.75

100 +

$152.92
