031-5329 by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

031-5329

RF Connector BNC Straight PCB Jack Through Hole 50 Ohm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tray Packaging
Accessories
Certificate of Compliance

DESCRIPTION

031-5329 is a BNC straight printed circuit board jack connector designed for 50O RF applications. It features a nickel-plated brass body with gold-plated beryllium copper contacts and a blunt post (flush) mounting style suitable for PCB integration. The connector is rated for industrial-grade applications and accommodates a 3-leg long post terminal measuring 0.040 inches (1.0 mm) in diameter and 0.125 inches (3.2 mm) long, with a 0.025-inch (0.6 mm) flush depth. BNC connectors are miniature quick-connect/disconnect RF connectors usable up to 11 GHz with low reflection through 4 GHz, making them ideal for cable termination and PCB-mounted RF signal distribution in test equipment, instrumentation, and communication systems.

Search Keywords: 0315329

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5329
Alias/AKA:
31-5329
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
160
Package Type:
Tray
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
11 x 17 mm

IN STOCK: 0

Manufacturer Stock: 16   can ship 8/24/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks can ship 11/13/26

Price (USD)

Qty
Unit Price
5
$9.68
25
$8.44
50
$7.95
160
$7.20
320
$6.91
640
$6.58
1,120 +
$6.19
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
