031-5538-10RFX by amphenol rf

031-5538-10RFX

Amphenol RF

RF Connector BNC Right Angle PCB Jack Through Hole Bulkhead 50 Ohm ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMPHENOL RF part 031-5538-10RFX is a high-quality RF connector designed for BNC applications. It features a right angle PCB jack configuration, making it ideal for use in tight spaces or when a low-profile connection is required. This connector is specifically designed for through-hole mounting, ensuring a secure and reliable connection. With a impedance of 50 Ohm, it is suitable for a wide range of RF applications. The bulkhead design further enhances its versatility, allowing for easy integration into various devices and systems. Whether you need a reliable RF connection for communications equipment, test and measurement devices, or other electronics, the AMPHENOL RF 031-5538-10RFX is an excellent choice.

Search Keywords: 031553810RFX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5538-10RFX
RoHS:
Yes
HTS:
8536694010
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tray
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
34.8 x 14.4 mm

IN STOCK: 4,356

Ships today, if you order in

Manufacturer Stock: 960   can ship 12/1/25

Minimum Order: 25

Multiple: 25

Factory Lead-Time 11 Weeks can ship 2/5/26

Price (USD)

Qty
Unit Price
25
$4.553
50
$4.336
100
$4.141
250
$3.811
500
$3.574
1,000
$3.461
2,500
$3.440
5,000 +
$3.430
