031-5660 by amphenol rf
Image is representational - see mfr. specs

031-5660

Amphenol RF

RF / Coaxial Connector, TNC Coaxial, Right Angle Bulkhead Jack, Solder, 50 ohm, Beryllium Copper ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

031-5660 is a TNC jack right angle PCB mount RF connector designed for high-frequency signal transmission applications. It features a 50 ohm impedance with a frequency range from DC to 11 GHz and offers a mechanical durability of 5000 mating cycles minimum. The connector body is constructed from zinc diecast with nickel plating, while the female contact uses beryllium copper with gold plating and the male contact is brass with gold matte tin finish. The insulators are made from PTFE and PBT materials, and the connector operates within a temperature range of -40°C to +85°C. This connector is suitable for telecommunications, test equipment, and wireless infrastructure applications requiring reliable RF connections with right angle PCB mounting.

Search Keywords: 0315660

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5660
Alias/AKA:
31-5660
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tray
Type:
TNC
Impedance:
50 Ohm
Operating Frequency:
N/A
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C
Dimension:
14.73 x 38.1 x 15.87 mm

IN STOCK: 56

Ships today, if you order in

Manufacturer Stock: 1,813   can ship 7/17/26

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 13 Weeks can ship 10/2/26

Price (USD)

Qty
Unit Price
5
$28.18
10
$28.11
25
$28.04
50
$17.25
75
$13.66
100 +
$13.39
Suppliers Standard Package
