031-5998-RFX by amphenol rf
Image is representational - see mfr. specs

031-5998-RFX

Amphenol RF

RF Connector BNC Straight Crimp Plug for RG-59 RG-140 Belden 8214 9913 9914 50 Ohm ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 031-5998-RFX is a BNC straight crimp plug connector designed for miniature to subminiature coaxial cable termination in RF applications. It features a nickel-plated brass body with gold-plated beryllium copper contacts, utilizing a crimp termination method for both the center conductor and cable braid. This commercial-grade connector is rated for 50 O impedance with performance specifications including a frequency range of DC to 4 GHz, a maximum VSWR of 1.16 at DC to 3 GHz, and a minimum shielding effectiveness of 55 dB at 3 GHz. The connector employs a 2-stud bayonet lock coupling mechanism (MIL-STD-348) for quick quarter-turn mating and is suitable for applications requiring reliable RF signal transmission in test equipment, instrumentation, and communication systems.

Search Keywords: 0315998RFX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5998-RFX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
-65 to 165 °C
Dimension:
34.5 x 14.5 mm

IN STOCK: 59

Can Ship immediately

Manufacturer Stock: 162   can ship 6/8/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks can ship 8/24/26

Price (USD)

Qty
Unit Price
5
$7.92
25
$7.52
50
$7.34
100
$7.24
250
$6.89
500
$5.89
1,000 +
$5.27
