031-9-75RFX by amphenol rf
Image is representational - see mfr. specs

031-9-75RFX

Amphenol RF

Conn BNC Adapter 0Hz to 4GHz 75Ohm RA RCP/PL Gold ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 031-9-75RFX is a 75 O BNC angle jack-plug adapter designed for commercial-grade RF connectivity applications. This connector features a nickel-plated brass body with gold-plated beryllium copper or phosphor bronze contacts, providing excellent corrosion resistance and reliable signal transmission. The adapter operates across a frequency range of DC to 1 GHz with a nominal impedance of 75 O, delivering a VSWR of 1.0 + 0.25f (GHz) and insertion loss of 0.2 dB maximum at 3 GHz. It employs a 2-stud bayonet lock coupling mechanism (MIL-STD-348) with a coupling torque range of 0.6 to 2.5 in-lbs, ensuring secure mating with quarter-turn engagement. The connector is rated for operation from -65°C to +165°C and supports 500 mating cycles minimum, making it suitable for test equipment, instrumentation, and video/RF signal distribution systems requiring 75 O impedance matching.

Search Keywords: 031975RFX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-9-75RFX
Alias/AKA:
B5072B1-001-ND3G-75
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
0 to 1 Hz to GHz
Gender:
RCP/PL
Mounting:
N/A
Body Orientation:
Right Angle
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
N/A

IN STOCK: 383

Ships today, if you order in

Manufacturer Stock: 457   can ship 6/15/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks can ship 9/1/26

Price (USD)

Qty
Unit Price
5
$8.32
25
$6.92
50
$6.52
100
$6.15
250
$5.77
500
$5.49
1,000 +
$5.15
