Image is representational - see mfr. specs

112348

Amphenol RF

RF Connector - BNC Straight Clamp Plug for RG-58 LMR-195 50 Ohms ...

Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 112348 is a DNC clamp plug connector manufactured by Amphenol RF for use with RG-58/U, 58/U, 12A/U, and 223/U coaxial cables. The connector features a brass contact pin with gold finish and a brass hex nut with nickel finish, along with a silicone gasket for reliable sealing. Key dimensional specifications include a cable stripped length of 14.50 mm, a flare dimension of 8.30 mm, and a hex nut size of 9.5 mm on flats, with overall assembly dimensions of 23.20 mm in length. This clamp plug design is commonly used in RF and microwave applications where secure cable termination and environmental protection are required, providing a robust connection suitable for field installation and maintenance scenarios.

Product Highlights:

Potential Applications:

Search Keywords: 112348

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol RF

Part No:

112348

Alias/AKA:

B1141C1-ND3G-58U-50

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694010

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
