132194RP by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

132194RP

RF Connector SMA Right Angle Crimp Plug for RG-55 RG-142 RG-223 50 Ohm Reverse Polarized ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 132194RP is an SMA reverse-polarity right-angle crimp plug connector designed for use with RG223/U and 400/U coaxial cables. The connector features a brass body and shell with gold finish, a beryllium copper contact pin with gold plating, and a PTFE insulator, providing excellent electrical and mechanical performance. Key dimensional specifications include a 1/4–36UNS–2B thread interface, with critical dimensions of 17.10 mm body length, 13.10 mm width, and a 3.10 mm ferrule diameter, along with a 6.35 mm outer diameter specification. The ferrule is crimped with a hex crimp size of 0.213 inches (5.41 mm), and the contact pin is designed for solder attachment. This connector is commonly used in RF and microwave applications requiring reliable, low-loss connections with reverse-polarity protection for cable assemblies.

Search Keywords: 132194RP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
132194RP
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
SMA
Impedance:
50
Operating Frequency:
12.4 GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Right Angle
Terminate To:
RG223/U Cable,RG400/U Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
17.1 x 15.9 mm

IN STOCK: 69

Can Ship immediately

Manufacturer Stock: 1   can ship 11/16/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 2/8/27
