132294-11

Name: 132294-11
Brand: Amphenol Rf
SKU: 48921694
Price: 437.35 USD
Availability: BackOrder

RF Connector - SMA Straight Solder Plug for .085 Semi-Rigid 50 Ohms ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

The 132294-11 is an SMA semi-rigid plug connector with contact pin integrated in the body, specifically engineered for 0.085" and 0.086" diameter cable applications. The connector features a stainless steel nut with passivated finish, a brass body with gold plating, a Teflon insulator, and beryllium copper contact pins with gold plating, ensuring excellent electrical conductivity and corrosion resistance. The connector has a 1/4–36UNS–2B thread specification with a body diameter of 3.20 mm (0.126 inches) and an overall length of 11.20 mm (0.441 inches), with four equally-spaced stakes 90° apart for mechanical stability. This connector is ideal for RF and microwave applications requiring reliable semi-rigid cable termination with precise dimensional tolerances and superior contact performance.

Product Highlights:

Potential Applications:

Search Keywords: 13229411

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol RF

Part No:

132294-11

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694010

COO:

ECCN:

EAR99
