Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

172219

RF Connector N Type Right Angle Crimp Plug for RG-8X LMR-240 50 Ohm ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

172219 is an N-type right-angle crimp plug connector designed for use with LMR 240 and 8X coaxial cables. The connector features a brass nut with Nexcote finish, a gold-plated brass contact pin, a Teflon insulator body, and a copper ferrule with Nexcote finish. It utilizes a crimp termination method with a hex crimp size of 0.255 inches and requires soldering for the contact pin. The connector has a 5/8-24 UNEF thread interface and an overall length of approximately 30.70 mm (1.210 inches). This connector is ideal for RF applications requiring reliable right-angle connections in telecommunications, wireless infrastructure, and test equipment.

Search Keywords: 172219

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
172219
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
Type N
Impedance:
50 Ohm
Operating Frequency:
0 to 11 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Right Angle
Terminate To:
Coaxial Cable
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
30.7 mm

IN STOCK: 680

Ships today, if you order in

Manufacturer Stock: 1   can ship 8/17/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks can ship 11/5/26

Price (USD)

Qty
Unit Price
5
$16.51
25
$14.06
50
$13.26
100
$12.63
250
$11.95
500
$11.27
1,000 +
$11.24
