901-143 by amphenol rf

901-143

Amphenol RF

RF Connector SMA Right Angle PCB Jack 50 Ohm ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMPHENOL RF part 901-143 is a high-quality RF connector designed for SMA right angle PCB jack applications. Offering a 50 Ohm impedance, this connector ensures efficient signal transmission for a wide range of electronic devices. With its sturdy construction and reliable performance, it is an ideal choice for professionals in the field of RF technology and circuit design.

Search Keywords: 901143

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
901-143
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
15.1 x 9.86 mm

IN STOCK: 783

Ships today, if you order in

Manufacturer Stock: 1   can ship 12/1/25

Factory Lead-Time 11 Weeks can ship 2/5/26

Price (USD)

Qty
Unit Price
1
$25.657
10
$21.517
25
$18.962
50
$16.604
100
$15.254
250
$14.307
500 +
$13.843
Suppliers Standard Package
Log in for special pricing
Click for Quote
