901-294 by amphenol rf
Image is representational - see mfr. specs

901-294

Amphenol RF

Conn Type N-SMA Adapter 0Hz to 11GHz 50Ohm ST PL/RCP Gold ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

901-294 is a straight between-series RF adapter designed to connect N Plug to SMA Jack interfaces. This adapter features a VSWR of 1.3 maximum over a frequency range of DC to 12.4 GHz, ensuring reliable signal transmission with minimal reflection. The adapter has overall dimensions of 1.66 inches (42.1 mm) in length and 0.812 inches (20.6 mm) in diameter, with a 0.500 inch (12.7 mm) hex wrench flat for secure installation. Ideal for RF test and measurement applications, telecommunications, and wireless systems where conversion between N-type and SMA connector interfaces is required.

Search Keywords: 901294

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
901-294
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
Type N-SMA Adapter
Impedance:
50 Ohm
Operating Frequency:
0 to 12.4 Hz to GHz
Gender:
PL/RCP
Mounting:
N/A
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
42.1 x 20.6 mm

IN STOCK: 16

Ships today, if you order in

Manufacturer Stock: 1   can ship 6/15/26

Factory Lead-Time 13 Weeks can ship 9/3/26

Price (USD)

Qty
Unit Price
1
$137.70
5
$135.28
10
$134.23
20
$133.19
50
$131.81
100 +
$123.15
