903-284P-52S by amphenol rf
Image is representational - see mfr. specs

903-284P-52S

Amphenol RF

The 903-284P-52S is a 50 ohm SubMiniature B (SMB) coaxial plug connector. ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 903-284P-52S is a 50 ohm SMB (SubMiniature B) coaxial plug connector from a series designed for broadband applications. These connectors feature a quick connect/disconnect snap-on mating mechanism that reduces installation time. The series offers broadband performance with low reflection from DC to 4 GHz and conforms to the requirements of MIL-C-39012, with an interface compliant with MIL-STD-348. Common applications include antennas, base stations, instrumentation, PC/LAN, telecom, and test and measurement equipment.

Search Keywords: 903284P52S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
903-284P-52S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
SMC
Impedance:
50 Ohm
Operating Frequency:
0 to 10 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
26.2 x 6.6 mm

IN STOCK: 25

Ships today, if you order in

Manufacturer Stock: 1   can ship 5/4/26

On Order: 100   can ship 6/26/26

Factory Lead-Time 13 Weeks can ship 7/23/26

Price (USD)

Qty
Unit Price
1
$37.14
5
$33.93
10
$28.76
25
$26.57
50
$26.50
100
$26.30
250 +
$25.76
Log in for special pricing Click for Quote Price Match Request
