APH-BNCJ-HDBNCP by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

APH-BNCJ-HDBNCP

Conn BNC Adapter PL/F 0Hz to 3GHz 75Ohm ST Gold Bag ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The APH-BNCJ-HDBNCP is a 75-ohm BNC plug to HD-BNC jack adapter designed to interface between standard BNC and high-density BNC connectors in RF and microwave systems. It features a 75-ohm impedance with a frequency range of DC to 3 GHz and a minimum return loss of -25 dB, ensuring excellent signal integrity across the operating bandwidth. The connector is constructed with brass and nickel-plated body components, beryllium copper contacts with gold plating, and PTFE insulation, providing durability and reliable performance over a temperature range of -65°C to +165°C with a minimum mechanical durability of 500 mating cycles. This adapter is ideal for test equipment, instrumentation, and RF systems where impedance matching and signal fidelity are critical requirements.

Search Keywords: APHBNCJHDBNCP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
APH-BNCJ-HDBNCP
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
0 to 3 Hz to GHz
Gender:
PL/F
Mounting:
N/A
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
29.32 x 12 mm

IN STOCK: 5

Can Ship immediately

Manufacturer Stock: 1   can ship 11/9/26

On Order: 25   can ship 1/13/27

Factory Lead-Time 14 Weeks can ship 2/1/27
