SMP-MSLD-PCR

RF Connector SMP Straight PCB Jack Limited Detent Rear Mount 50 Ohm ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SMP-MSLD-PCR is a rear-mount limited detent SMP connector assembly designed for PC board integration. It features a 50-ohm impedance with a frequency range from DC to 12 GHz, supporting VSWR specifications of 1.10 (26 dB) maximum from DC to 6 GHz and 1.20 (21 dB) maximum from 6 to 12 GHz. The connector is constructed with a brass body and beryllium copper contacts, both gold-plated to 0.00030 inch (0.0008 mm) thickness over copper, with a PEEK or LCP insulator rated to UL94 V-0. It offers robust mechanical performance with 500 cycles minimum durability, engagement force of 10 lb (45 N) maximum, and operates reliably across a temperature range of -65°C to 165°C. This connector is ideal for high-frequency RF applications, test equipment, and precision instrumentation requiring reliable, repeatable connections.

Search Keywords: SMPMSLDPCR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
SMP-MSLD-PCR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
TRAY
Type:
SMP
Impedance:
50 Ohm
Operating Frequency:
0 to 40 Hz to GHz
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 155 °C
Dimension:
N/A

IN STOCK: 23

Can Ship immediately

Manufacturer Stock: 469   can ship 10/5/26

MOQ for out of Stock Qty: 25

Factory Lead-Time 14 Weeks can ship 12/29/26
