AHD17-PN01

Name: AHD17-PN01
Brand: Amphenol Sine Systems
SKU: 49189076
Price: 36.1 USD
Availability: InStock

Jam Mount Diagnostic Receptacle Nut ...

View Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

The AHD17-PN01 is a 9-position jam mount receptacle nut designed for use with Amphenol Sine Systems AHD Series circular thermoplastic connectors. This accessory is specifically engineered for PE and PES extended shell pin receptacles in J1939 Type 1 (black body) configurations. The nut features a thermoplastic UL94-VO housing body and is rated for operating temperatures from -55°C to +125°C, with an IP67 rating in mated condition. It supports the connector's 13A maximum current rating and 250V voltage rating, maintaining reliability across demanding industrial diagnostic and data communication applications including heavy-duty vehicles, marine propulsion, and construction equipment.

Product Highlights:

Potential Applications:

Search Keywords: AHD17PN01

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AHD17-PN01

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

3926909989

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
