AHDP06-24-16SR-BRA by amphenol sine systems

Image is representational - see mfr. specs

AHDP06-24-16SR-BRA

A 16-position, size 24 circular plug from the DuraMate AHDP series, featuring a plastic shell, size 12 socket contacts, and a backshell ring adapter. ...

Datasheet

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The AHDP06-24-16SR-BRA is a heavy-duty circular plug from the DuraMate™ AHDP series, designed for harsh environments. It features a size 24 thermoplastic shell with a bayonet coupling mechanism and houses 16 size 12 socket contacts, each rated for up to 25A. This connector is equipped with a reduced diameter rear seal and a Backshell Ring Adapter (BRA) for use with various snap-on backshells. With an IP68/IP69K rating when mated and an operating temperature range of -55°C to +125°C, it ensures reliable performance in off-road, agricultural, and industrial applications.

Product Highlights:

Potential Applications:

Search Keywords: AHDP062416SRBRA

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AHDP06-24-16SR-BRA

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
