AHDP06-24-19SR-BRA by amphenol sine systems

Image is representational - see mfr. specs

AHDP06-24-19SR-BRA

The AHDP06-24-19SR-BRA is a heavy-duty, environmentally-sealed, 19-position circular plug connector from the DuraMate AHDP series. ...

Datasheet

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The AHDP06-24-19SR-BRA is a shell size 24, 19-position circular plug from the DuraMate AHDP series, designed for reliable connections in harsh environments. It features a high-strength thermoplastic housing with a circular bayonet locking system for secure mating. The connector is configured with 19 socket contacts, comprising six size 12 contacts rated for 25A and thirteen size 16 contacts rated for 13A, and includes a reduced diameter rear seal. This model is equipped with a Backshell Ring Adapter (BRA), allowing for use with compatible industry-standard snap-on backshells. With an operating temperature range of -55°C to +125°C and an IP69K rating when mated, it provides robust protection against dust, high-pressure water, and contaminants, making it ideal for off-road, agricultural, and heavy-duty industrial applications.

Product Highlights:

Potential Applications:

Search Keywords: AHDP062419SRBRA

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AHDP06-24-19SR-BRA

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
